international size rating 1500-518 CLAMPING UNIT Clamping force 1500KN Opening stroke 400mm Max.daylight 850mm Platen size 660 x 640mm x mm Space between 430 x 420mm x mm Max.mold height 450mm Min.mold height 215mm Ejector stroke 125mm Ejector force 45KN INJECTION UNIT Screw diameter 38 42 48mm Screw L/D Ratio 23.2 21 18.4 Injection Pressure 212 174 133MPa Shot volume 243 298 389cm3 Shot weight(PS) 216 265 346g(克) 7.6 9.4 12.2OZ(盎司) Injection rate (PS) 83 103 136g /sec Plasticizing capacity (PS) 17 22 30g /sec Screw stroke 215mm Screw speed 216rpm POWER UNIT Hydraulic system Pressure 16.0MPa Pump motor power 15kW Heater power 8.0kW GENERAL Dry-cycle time 1.5Sec Oil tank capacity 200L Machine weight 4.3Ton Machine dimensions (L×W×H) 4.6 x 1.15 x 1.8m x m x m
