international size rating 2200-797 CLAMPING UNIT Clamping force 2200KN Opening stroke 500mm Max.daylight 1065mm Platen size 780 x 750mm x mm Space between 510 x 490mm x mm Max.mold height 565mm Min.mold height 250mm Ejector stroke 145mm Ejector force 75KN INJECTION UNIT Screw diameter 46 50 58mm Screw L/D Ratio 22 20 17 Injection Pressure 202 166 123MPa Shot volume 408 480 645cm3 Shot weight(PS) 362 428 575g(克) 12.8 15 20.3OZ(盎司) Injection rate (PS) 113 132 178g /sec Plasticizing capacity (PS) 28 35 52g /sec Screw stroke 245mm Screw speed 163rpm POWER UNIT Hydraulic system Pressure 15MPa Pump motor power 18.5kW Heater power 11kW GENERAL Dry-cycle time 2.5Sec Oil tank capacity 300L Machine weight 6.8Ton Machine dimensions (L×W×H) 5.46 x 1.45 x 2.1m x m x m
